Collins, A. Frederick (Archie Frederick), 1869- · Boston, Small, Maynard and company · leaf 97
d file a slot %2 inch wide and % inch deepas shown at M in Fig. 31 so that the thin end ofthe connecting rod will fit in it. Put a pinthrough the bearing and the connecting rod and,while it must fit the bearing tight, the connectingrod must swing easily on it. The Crank and Crankshaft.—Drill a… … ctSu u obe ad> oU > O • ¥■* CO E 82 A V24-H. P. Horizontal Steam Engine 83 Drill a /46-inch hole through the large end ofthe crank at right angles to and through it, untilit meets the hole drilled for the crankshaft;thread the hole and put in a screw pointed at theend for the set screw. Now…
Steam-engines
