rmed by having them twoor more bricks deep, or they may be rough andturned in half-brick rings, 4>^ inches thick, asshown at hh in Fig. 140. In arches of quickcurve, with not more than 2 or 3 feet radius,this method is absolutely necessary to prevent 140 ARCHII^fiCTURAL DRAWING SELF TAtTGH!^…
