Builder's architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1903)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919 · Chicago : F.J. Drake & Co. · leaf 193
s,and fellows who havenot had a fairly goodopportunity of ac-quiring a knowledgeof either drawing orconstruction, but whoare desirous of learn-ing what they can ofboth, during theirspare moments. The plates, follow-ing the general illus-trations, will place before the student manythings not as yet… … Fig. 156. 156 ARCHITECTURAL DRAWING SELF TAUGHT good example for drawing; its proportions arenearly perfect, and the style is modern. This isan inside door as shown by the base. The sliding doors shown at Fig. 157 are verynearly built in the same style as the single door
Architectural drawing
