that any part which may be toofull or too flat may be improved before thehusks, flowers, foliage, or other details areadded. The ornament shown in Fig. 202 is called theEchinus, the ^g^ and tongue, or ^g% and dartmoulding. It is much used by carvers forborders and similar work. v^ 184… … Fig. 204. be turned in a lathe and then split in two orquartered. Fig. 204 shows the Greek conventional lilyform. It has a faint resemblance to theEgyptian lotus, but has a Grecian delicacyabout it that is absent in Egyptian forms. The ornament shown in Fig. 205 is the Greek ARCHITECTURAL DRAWING…
