Builder's architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1903)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919 · Chicago : F.J. Drake & Co. · leaf 53
draw-ing pen, and asix inch flatscale. This casecan be boughtfor about $4.00,for which sum instruments ought to be fairly good;if, however, the student can afford it, and feelsthat he had better purchase a set of instrumentsthat will meet all his needs, present and future,why then he had better… … Fig. 19. ARCHITECTURAL DRAWING SELF TAUGHT 37 contains, besides the box, one 5^ in. dividers,with pen, pencil and needle points, lengtheningbar; 3>^ in. dividers, with pen, pencil and needlepoints; 5 in. plain dividers; 5 in. hair spring
Architectural drawing
