Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 119
ller dimensions shouldexactly agree with the over-all measurement given. In drawing pencil linesthey should always beJ / I drawn longer than the ac- ^ X. Dl tual length of the lines tobe inked in, so that theexact point of intersectionwith other lines can be betterseen. When the drawing has been… … Fig. 97. ARCHITECTURAL DRAWING SELF TAUGHT 105 of the finished drawing. These constructionlines, as they are called, should be drawn aslightly as possible, so as to be easily removedwithout greatly damaging the surface of thepaper. When drawing circles or arcs of circleswith the compasses, a little…
Architectural drawing · Architecture, Domestic
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
