Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 134
. It doesvery well for garden walls, retaining walls, cel-lar walls for small buildings, but should not beused where great strength is required. Block course masonry is where the courses ofstone run in straight horizontal lines as shown,at Fig. III. Ashler masonry is built up incourses of more or… … Fig. no. 118 ARCHITECTURAL DRAWING SELF TAUGHT by different names, according to the face putupon the stone—from quarry-pitched, or rockashler, to wrought ashler. A sample of the workis shown in Fig. 112. There are many other forms of stonework,but the examples given are quite sufficient forthe…
Architectural drawing · Architecture, Domestic
