Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 193
again by the introduction of small circles at thejunction of the lines, as shown in one instance.This may again be elaborated by adding a lineor dot to the circle as shown. Another example formed of squares and half 17C ARCHITECTURAL DRAWING SELF TAUGHT squares is shown in V\g. i8i. This…
Architectural drawing · Architecture, Domestic
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
