Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 194
. In startingand ending a line, endeavor to have the lineclear and distinct and of an even thickness asshown in the example. Lines must not be leftshort, but must join the cross lines as thoughthey were under them. To draw a panel ofinterlacing strap work, as shown in example,without a flaw, is… … g^(^ Fig. 183. Fig. 184.
Architectural drawing · Architecture, Domestic
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
