Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 195
good one to follow for practice. Fig. 184 is a modifica-tion of the same orna-ment, a quarter circle be-ing used on all externalangles instead of havingthe lines join with a rightangle. In other words, the ornament is a com-bination of curves and straight lines. Copy these examples four or five… … Fig. i86. purely Greek examples, the first being thesimplest form of running Greek fret. Its con-struction is very simple and easy, and may be reproduced with aT and set squaresalone. Fig. 185 isconstructed nearlyin the same man-ner, there beingtwo more anglesin the latter than the former. The next…
Architectural drawing · Architecture, Domestic
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
