Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 224
Fig. 219. sufficient to give the student a good insight intoGothic tracery work, bui it must be rememberedthat in Gothic work the designs of this characterare innumerable. Portions of these designs are ARCHITECTURAL DRAWING SELF TAUGHT 197 used in window and door heads, and in ahundred other… … Fig. 220. foundation of the whole of the work. All theother ornamentation seems to cluster aroundthe three larger circles; this is the peculiarityof these two examples, but it must be borne in 198 ARCHITECTURAL DRAWING SELF TAUGHT mind that the trefoil is not the only basis aroundwhich the old…
Architectural drawing · Architecture, Domestic
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
