Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 32
Fig. 9. ARCHITECTURAL DRAWING SELF TAUGHT 27 The set square or squares, similar to thoseshown at Fig. 9, C, D, K and B, are great aids … Fig. 10. to drawing as they may be employed in conjunc-tion with the T-square, for lining off angles, orlaying off parallel lines as shown by the dottedlines EG, and FH. These set squares are made Fig. II. to suit different angles, and in many styles,as will be seen in Fig. 11. The manner of 28…
Architectural drawing · Architecture, Domestic
