Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 44
4 in. dividers,with pen, pencil and needle points, lengtheningbar; T)/^ iri- dividers, with pen, pencil and needlepoints; 5 in. plain dividers; 5 in. hair spring … Fig. 20. ^ dividers; spring bow dividers, pen and pencil,needle points, ivory handle; 4.}4 in. ivory handlehinged drawing pen, needle point; 5>^ in. ivoryhandle hinged drawing pen, needle point;German silver protractor, ebony rule and scale. 38 ARCHITECTURAL DRAWING SELF TAUGHT These instruments…
