Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 66
i in. radius, and, lastly to 1% in.radius, checking the curves before actually ARCHITECTURAL DRAWING SELF TAUGHT 57 drawing them, by seeing how they fit with thosealready drawn. Here is an example, Fig. 36, made upaltogether with curved lines and which offersgood practice. This re-quires accurate…
Architectural drawing · Architecture, Domestic
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
