w e want to draw a portion of a circle. Let BHCbeachord of the segment H, and BJA a chord enclosing t n e segment. Bisect or divide m equal parts the chord BC at H, and square down from this point to D. Do the same with the chord AJB, squaring over from J to D, then the point where JD and HD… … 62 ARCHITECTURAL DRAWING SELF TAUGHl Suppose AB, Fig. 44, to be the curve, from thepoint A and B strike ares of equal radius inter-
