Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 99
thefollowing examples numbered from Fig. 76 to78 inclusive, which the student is advised to 86 ARCHITECTURAL DRAWING SELF TAUGHT draw and redraw, first by measuring off thedistances, and then by attempting to get theexact distances without measurement. If theHnes in the examples are placed less… … Fig. 76. Fig. 77- Fig. 78. kind of work makes excellent practice for thepen. These examples are selected from a largenumber of possible combinations, as givingvariety of practice while not appearing toodifficult. They are, however, more difficultthan they appear, so that they must be com-menced…
