The builder's dictionary, or, Gentleman and architect's companion : explaining not only the terms of art in all the several parts of architecture, but also containing the theory and practice of the various branches thereof ... : also necessary problems in arithmetic, geometry, mechanics, perspective, hydraulics, and other mathematical sciences : together with the quantities proportions, and prices of all kinds of materials used in building ... (1734)

Toms, W. H. (William Henry), ca. 1700-ca. 1750, Devoto, John, fl. 1719-1752 · London : Printed for A. Bettesworth and C. Hitch ..., and S. Austen ... · leaf 28

An illustration from The builder's dictionary, or, Gentleman and architect's companion : explaining not only the terms of art in all the several parts of architecture, but also containing the theory and practice of the various branches thereof ... : also necessary problems in arithmetic, geometry, mechanics, perspective, hydraulics, and other mathematical sciences : together with the quantities proportions, and prices of all kinds of materials used in building ..., 1734, leaf 28 — ination is greater from oneanother, than the Lines of theRight Angle, as the Angles madeby the Meeting of the LinesFC and CB, or AC and EB,by which they form Angles thatare more blunt than the RightAngle, and therefore are calledObtufe Afiglcs. lb make the Angle FHKequal to the Angle C A E. Ftrft^…

Architecture · Building

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
