The builder's dictionary, or, Gentleman and architect's companion : explaining not only the terms of art in all the several parts of architecture, but also containing the theory and practice of the various branches thereof ... : also necessary problems in arithmetic, geometry, mechanics, perspective, hydraulics, and other mathematical sciences : together with the quantities proportions, and prices of all kinds of materials used in building ... (1734)
Toms, W. H. (William Henry), ca. 1700-ca. 1750, Devoto, John, fl. 1719-1752 · London : Printed for A. Bettesworth and C. Hitch ..., and S. Austen ... · leaf 227
incipalRafters, and their Breadth ac-cording to the Bignels of themthat are intended to be let intothem, the middle Part beingleft fomething broader than theThicknefs. RAG-STONE, fee TdvhiQ-,R AKEING. SuppofetheLevel Moulding A join therakeing Moulding B. How tomake their Curves to fit eachother at… … From thence raifc Perpendi-culars to the Curves, as m theExample 5 and draw the LineD E Perpendicular to D K. When you have done this,draw the Line G I and H FPerpendicular to KN, and di-ilant from each other, equal toE C, and draw the Line H G,which divide in the middleinO. Then divide H O into…
