The builder's dictionary, or, Gentleman and architect's companion : explaining not only the terms of art in all the several parts of architecture, but also containing the theory and practice of the various branches thereof ... : also necessary problems in arithmetic, geometry, mechanics, perspective, hydraulics, and other mathematical sciences : together with the quantities proportions, and prices of all kinds of materials used in building ... (1734)

Toms, W. H. (William Henry), ca. 1700-ca. 1750, Devoto, John, fl. 1719-1752 · London : Printed for A. Bettesworth and C. Hitch ..., and S. Austen ... · leaf 385

An illustration from The builder's dictionary, or, Gentleman and architect's companion : explaining not only the terms of art in all the several parts of architecture, but also containing the theory and practice of the various branches thereof ... : also necessary problems in arithmetic, geometry, mechanics, perspective, hydraulics, and other mathematical sciences : together with the quantities proportions, and prices of all kinds of materials used in building ..., 1734, leaf 385 — T I Triangles in as plain and fami-liar Method as poffible. OfrefoVvin^ Triangles.THEOREM I. In any right-angled Triangleif either of the Legs be madeRadius, the other Leg will bethe Tangent of its oppofite An-gle, f. g. If AD be made Radi-us, BD will be Tangent of theArch d D= BAD 3 and if BDbe…

Architecture · Building

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
