Building construction and superintendence, by F.E. Kidder ... (1896)
Kidder, Frank E. (Frank Eugene), 1859-1905 · New York, W.T. Comstock · leaf 320
an initial strain on the arch. This form of girder is comparativelylittle used now, but there may be con-ditions, as in the church mentionedabove, where it can be used to advan-tage. 325. Supports for Bay Win-dows.—Where bay windows havingwalls of brick, stone or terra cottastart above the first… … 306 B (-/LDIXG CONSTR UCTION. beling out the stonework as shown in Fig. 213. The stoned shouldbe the full size of the bay if possible, and should be bolted down bymeans of long rods built into the wall and secured to two channelbars (as in the figure) placed on top of the stone and with theirends…
