mns that carry any weight should notbe less than f-inch thick, and should be cast straight from end toend; under no circumstances should a supporting column be cast asin Fig. 469. If the column is to be loaded with 60 per cent, of itscalculated safe load, the thickness of the metal should be tested… … Fig 469. 454 BUILDING CONSTRUCTION. The ends of all posts should be turned in a lathe to a true planeat right angles to the axis of the columns. The lower post shouldrest on a cast iron plate with a raised cross cast on it to fit into thecolumn. The portion of the plate which receives the column…
