Gf> BUILDING CONSTRUCTION. device for securing ventilation around the joist (when built into thewall) that the author is acquainted with is the Goetz Box Anchor,shown in Fig. 40. This holds the joist in position and at the sametime affords an air space, as shown in plan, Fig. 41. The second… … . 1 II 1 , iwrfflnirmiy j BtVEL If 1 ill Fig. 41. in the figure, and a corresponding notch is cut in the bottom of thejoist, so that when the joist is in place it is securely fastened to thebox, and, the latter being dovetailed into the wall, affords a sufficientanchor. Large beams or girders may…
