ken.As long as the plate and connections hold in-tact the rafters cannot spread. The hips may be made of a single timberor they may be trussed, in the manner indi-cated at A, A. To prevent distortion of theframe from unequal distribution of snow orfrom wind, diagonal ties should be intro-duced in… … Fig. 102 OCTAGONAL ROOFS WITH LANTERN. 157
