Fig. io8. Fig. 109. East. The rebate for the bottom of the sash is the same as in theprevious example, but the side rebates are different. The hollow inthe edge of the stop bead is made with the idea that if rain is driventhrough the rebates it will stop in this space and descend to the sill,where…
