Kidder, Frank E. (Frank Eugene), 1859-1905, Nolan, Thomas, 1857-1926 · New York : W.T. Comstock · leaf 241
ls and then veneeredwith two thicknesses of very fine veneer, as described in Section 165.Scribing.—This is the operation of bringing the edge of a piece ofwood, usually a long strip, to fit close to an irregular surface, as infitting the edge of a board to a plastered wall that is not a tiue… … Fig. 213. to cut off just enough to give the proper width to the board; onepoint is drawn along the irregular surface while the other is made toscratch a line on the face of the board, as shown by the dotted line,Fig. 212 This line will, of course, be exactly parallel to the profileof the surface,…
Building
