Kidder, Frank E. (Frank Eugene), 1859-1905, Nolan, Thomas, 1857-1926 · New York : W.T. Comstock · leaf 250
rong and good proportioned door and the panels arenot so wide as to cause excessive shrinkage. The two upper panelsmay be •eversed, as shown by the dotted lines, if desired. Fig. 224 shows a door having but a single panel, which may beused either as an inside door or as a front door. Figs. 225 and… … Fig. 236. 248 B UILDIN G CONS TR UCTION. must be made with much more care than doors with narrow panelsThe thickness of doors with large panels, such as is shown in Figs.224 and 226, should not be less than 2 inches for doors 3 feet 4inches wide and under, and 2\ inches for doors over that width.
Building
