Kidder, Frank E. (Frank Eugene), 1859-1905, Nolan, Thomas, 1857-1926 · New York : W.T. Comstock · leaf 313
Fig. 319- … Fig. 320. drawn out it slides first on the sliding piece S, and when half opena pin, y, engages in the sliding piece and draws it out. The piece Sholds the drawer and keeps it from falling. The slide S is preventedfrom tipping by the shoulder R, which bears against the under side ofof the piece A,…
