lconies in Abbeys Theatre, New York, Messrs. J. B,McElfatrick & Son, architects. For the support of the steppings in this theatre there are 8-inchsteel channels extending from a line of 12-inch beam girders betweenthe back columns to the inner circle lattice girders, and projectingnearly 10… … Fig. 459-2-inch battens secured to stepping pieces of i^xi^-inch steel angles,bolted to the radiating channels. The risers are made of sheet iron about yV of ^ ich thick andalso secured to the angles. The ceiling beneath was formed by bolting i|xi^-inch angles tothe under side of the channels every…
