Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter G. (Walter Gilman), 1858-1908 · New York, J. Wiley & Sons · leaf 161
Fig. 260.—Elevation. Fig. 159.—CROss-sEcrioN. ft. deep in the clear, 16 ft. i in. outside diameter at the bottom, and 15 ft. outside diameter at the top.The bottom of the floor of the tank is set 8 ft. 6 in. above the toji of rail, and the centre of the tank is IJ :i TF.K S TA TIONS. 123 set about…
