gers have to descend to get to the platform in front of the depot. There is anoverhead foot-bridge across the tracks, so that the other platforms can be reached by stairs leadingdown from this overhead bridge. Passenger Train-shed at Ne70 Haven, Conn., Ne7V York, Nc7v Haven & Hart/ord… … Fig. 630.—Cnoss SECTION ok Train-siiep. each of 63 ft. span. There are four tracks in each span spaced 15 ft. centres. The train-shed isused ai a terminal side-station, and the floor of the shed is floored flush with the rails. The posts andthe prim ipal rafters consist of channel-irons, the…
