Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter G. (Walter Gilman), 1858-1908 · New York, J. Wiley & Sons · leaf 456
the main trusses of the train-shed. Thelower end of these vertical trusses is supported by a horizontal truss, 14 ft. 6 in. deep, running across thetrain-shed and carrying the strain from wind-pressure to the end main truss at the top of the first section. TERMINAL PASSENGER DEPOTS. 417 In each… … chord of the end main truss. The end truss itself is finished with a corrucrated-iron covering;, panelled tocorrespond to the panels of the truss, and with false verticals and diagonals on the outer side, giving theappearance of a truss from the exterior. 4i8 BUILDINGS AND STRUCTURES OF AMERICAN…
Railroads -- Buildings and structures · Buildings
