Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter G. (Walter Gilman), 1858-1908 · New York, J. Wiley & Sons · leaf 467
out189 ft. out to out of roof. Sides of structure between posts are open, except such bracing as required for stability, and consistingof a 7-ft. deep latticed purlin-strut at top, and a 4-ft. deep plate-girder curtain strut, the bottom of which islevel with the top of car-windows, and which is… … Fig. 674.—Side Elevation of HEAD-Hr>iM and Tuain-shed.
