Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter G. (Walter Gilman), 1858-1908 · New York, J. Wiley & Sons · leaf 47
Fig. 17.—Front Elevation. Fig. iS.—Ground-plan. … 1 X: - 9& \ T Fig. in.—Sipk Elevation. Fig. 20. —Section. Fig. 21.—Elevation of Frame. are three standard sizes in use, viz.: size A, 16 ft. 2 in. X 30 ft. 2 in.; size B, 16 ft. 2 in. X 20ft. 2 in.; size C, 12 ft. 2 in. X 14 ft. 2 in. Tlie building is phiced either with the gable end or theside…
Railroads -- Buildings and structures · Buildings
