Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 128
Fig. 210,—Longitudinal Section. OIL-STORAGR HOUSES. 91 cal Engineer, C, I?. & Q. R. R., is a two-story briik strurture, 20 ft. 8 in. X 19 ft. 4 in., with cellar.The structure is firejiroof throughout. Iho foundations are stone walls. Jhe floor-beams,roof-purlins, and rafters are iron T-beams,… … Fig. 211.—Cross SECTION.
Building · Railroads
