. The bottom of the pocket is lined with ^^-va.. sheet-iron. The apron is counterweighted, asshown, and the bottom of the pocket is closed by a flap-door, which is opened and closed automati-cally with the lowering and raising of the apron. The apron is 5 ft. long. The pocket and apronslope 45… … Fig. 279.—Cross-section. consist of a timber trestle structure throughout, the coal being delivered onto a storage platformfrom a high dumping-trestle on the back of the platform and then shovelled as required into a seriesof pockets along the face of the platform, the top of the pockets being…
