Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 440
Fig. 64S.—Ground-plan of Main Floor.A, Smoking-room; B, Gentlemen; CC, Ambulatory; D, Package-room; E, Main Hall; F, Ladies; G, Dining-hall; //, Kitchen. … Fig. 649.—Ground-plan of Basement.A, Emigrant Waiting-room ; i, Ticket-office ; J/, Concourse ; N^ Barber-shop ; t?. Mail-room - P, Telegraph ; (?, Restaurant: i?, Carriage Concourse; T, Conductors Lobby. It is not proposed to cover the whole with a single-span roof, there being four rows of…
Building · Railroads
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
