Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 62
eChesapeake & Ohio Railway, known as plan L, designed by Mr. H. Jacob, are shown in Figs. 77 to79. The structure is a frame building, L-shaped, the main section 23 ft. X 35 ft. 6 in., with an annexfor a kitchen, 16 ft. X 12 ft. 6 in., and an anne.x for a chamber, 17 ft. X 17 ft. The… … Fig. 77.—Perspective.
