Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 86
es. The rack is 42 in. wide and 21 in. abovethe platform. It is slatted on top, so as to allow dust and dirt to drop to the ground. The tracks atthis point are spaced 20 ft. centres. The dimensions of the lumber are as follows: blocking, 6 in. X6 in.; floor-joists, 3 in. X 6 in.; flooring, 2 in.;… … Fig. 13S.—Side Elevation. platform shed of the Pennsylvania Railroad, shown in Figs. 138 to 140, was built in the latter part ofthe year 1890 for the use of the Pullman Car Company at the special cleaning and storage yard for that branch of the service at Jerse) City, N. J. Thereare several lines…
