Building stone, lathing, plastering, and tiling, common brickwork, ornamental brickwork and terra cotta : lighting fixtures, use and design of lighting fixtures, architectural design (1909)

International Correspondence Schools · Scranton : International Textbook Co. · leaf 155

An illustration from Building stone, lathing, plastering, and tiling, common brickwork, ornamental brickwork and terra cotta : lighting fixtures, use and design of lighting fixtures, architectural design, 1909, leaf 155
Fig. 12 splitting the face brick in half and backing the same with acontinuous row of headers. This last method is shown inFig. 12. The face brick cut lengthwise are shown at a. At bare the three-quarter bats bonding in back of the face brick.The whole brick c bonds on the inside of the wall,… … Fig. 13 45. Metal Ties for Brickwork.—Fig. 13 illustratesthe method of bonding in face brick with steel or galvanized-iron wire. These wire bonders b are twisted at the ends,and hold together the inside and outside courses a and c^ as §39 COMMON BRICKWORK 27 shown. They are laid in every sixth…

Building · Building materials · Architectural design · Lighting, Architectural and decorative
