Building stone, lathing, plastering, and tiling, common brickwork, ornamental brickwork and terra cotta : lighting fixtures, use and design of lighting fixtures, architectural design (1909)

International Correspondence Schools · Scranton : International Textbook Co. · leaf 265

An illustration from Building stone, lathing, plastering, and tiling, common brickwork, ornamental brickwork and terra cotta : lighting fixtures, use and design of lighting fixtures, architectural design, 1909, leaf 265
Fig. 15 constructed of various materials adapted to the purposedesired and should be placed about 5 feet 6 inches abovethe floor. The combination bracket shown in Fig. 15 isfurnished with a telescope, or bracket back a, designed sothat an adjustment can be made by screws b, as shown. Thisdevice… … §42 LIGHTING FIXTURES 13 14. Gas Column Brackets.—Brackets that are attachedto columns, or pillars, by bands encircling them are knownas column brackets. A four-light straight-gas columnbracket employing four bent arms in the circle is illustratedin Fig. 16, an elevation of the fixture being shown…

Building · Building materials · Architectural design · Lighting, Architectural and decorative
