Building stone, lathing, plastering, and tiling, common brickwork, ornamental brickwork and terra cotta : lighting fixtures, use and design of lighting fixtures, architectural design (1909)

International Correspondence Schools · Scranton : International Textbook Co. · leaf 284

An illustration from Building stone, lathing, plastering, and tiling, common brickwork, ornamental brickwork and terra cotta : lighting fixtures, use and design of lighting fixtures, architectural design, 1909, leaf 284
Fig. 35 Sectiona/ E/ei^ation … Bottom l/iety(b) wires, the tapped outlets for the electric arms being locatedat e, with setscrews under them, as shown. The rod for thependant knob is screwed into the tapped opening /, Thediameter of the body fitting and the number of gas and 32 LIGHTING FIXTURES §42 electric tappings depend on…

Building · Building materials · Architectural design · Lighting, Architectural and decorative

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
