Building stone, lathing, plastering, and tiling, common brickwork, ornamental brickwork and terra cotta : lighting fixtures, use and design of lighting fixtures, architectural design (1909)
International Correspondence Schools · Scranton : International Textbook Co. · leaf 296
Fig. 45 Fig. 46 Fig. 46 shows a one-light ceiling fixture constructed witha spun shell and furnished with a ground-glass globe, orball. The spun shell is placed on the ceiling and is held inposition by a holder a, which in turn is secured by the con-nection of the hickey with the insulating joint.… … Fig. 47 54. A cluster ceiling light with a spun shell and aground-glass dish is shown in Fig. 47. The spun shell ais held in position by a holder b that is secured by the 44 LIGHTING FIXTURES §42 connection of the body with the insulating joint. The ground-
