rgerollers on shaft A and below they are attaclied to lea-ther straps which pass around the rollers Kl and K2that are pivotted on brackets that are fixed to thebinders as shown. The top shaft A is driven from the ordinary heddleroller shaft B by means of the fixed bosses CI and C2, the latch is… … Fig. 1 and the bosses Dl and 1)2. The boss D2 is driven fromthe bosses C2 by cross straps and the boss Dl from thebosses CI by straight strap. These bosses, Dl and D2,are free to revolve upon the shaft A except when en-gaged by the latch E. which is pivotted upon thebracket F, this being fixed on…
