The car-builder's dictionary: an illustrated vocabulary of terms which designate American railroad cars, their parts and attachments (1879)

Master Car Builders' Association, Forney, Matthias N. (Matthias Nace), 1835-1908, Garey, Leander, Smith, Calvin A · New York : The Railroad Gazette · leaf 270

An illustration from The car-builder's dictionary: an illustrated vocabulary of terms which designate American railroad cars, their parts and attachments, 1879, leaf 270
Freight-car Trucks. 250 For list of names of the parts designated by the numbers in the engravings, see page 242. … Fig. 96. Longitudinal Section. T) T A Mn'CTVTRTT C K , CENTRAL riAILROAD OF NEW JERSEY.

Railroad cars

Internet Archive · Smithsonian Libraries · Public domain (published before 1931). Free to use for anything.
