The car-builder's dictionary: an illustrated vocabulary of terms which designate American railroad cars, their parts and attachments (1879)

Master Car Builders' Association, Forney, Matthias N. (Matthias Nace), 1835-1908, Garey, Leander, Smith, Calvin A · New York : The Railroad Gazette · leaf 316

An illustration from The car-builder's dictionary: an illustrated vocabulary of terms which designate American railroad cars, their parts and attachments, 1879, leaf 316
Car-springs. 296 … Fig. 198. Fig. 199. Fig. 200. Flat-bap. or Equal-bap. Edge-rolled Spiral-spring "Hibbard" or Flat-bar Spiral Triple-coil NEST-spsise. Spiral Quadruple-coil Nest-sprlng.

Railroad cars
