Card grinding in theory and practice : a treatise upon the various methods of grinding card clothing used by spinners of cotton, wool, silk, and other textile fibres (1922)
one ; thelargest is covered with leather. From the latter cone thefilleting passes over the lever (E) and goes directly to thecylinder in correct position ; this lever is mounted againstsprings, and the tension exerted upon it by the filletingactuates the indicating needle which registers the… … Fig. 16. Patent Indicating Tension Head, No. -59. Codeword—Tensilon. CARD MOUNTING. CYLINDERS AND DOFFERS. 35 card-teeth or face of the fillet. Secondly,—by means of ahand-manipulated brake-drum on the shaft of the coned pulleythe filleting is compelled to slide over the faces of the cones ;this…
Carding-machines · Textile machinery
