Fig. 628.—Conventional View of Trimming ancTGutter. … Fig. 629.—Trimming for Rafter against Chimney. the rafters If desired, the ridge can bfesupported on an iron corbel built into thechimney, but this is seldom considerednecessary. When trusses are provided theridge is further supported by them. The Fig. 630.—Supporting Purlin against^Chimneyby…
