Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 214
for a Large and a Small Dormer,in the Side and End of Hipped End Mansard Roof. Another North Country DormerWindow. The kind of dormer that is used whereit is desired to gain as much light as pos-sible is shown by Figs. 689 and 690. Fig. 689 framed with bars for glazing. At Fig. 691the trimming is…
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
