Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 217
ted by ashlering studswhich are fixed to them. or bed screws may be used ifjdesired.Fig. 697 shows the connections for the post,the head, and the top rail of light, thejoints being firmly held together by a boltinserted from the outside of the top rail.This bolt is passed through into the head… … Fig. 701.—View of Stone Dormer in End of completed Mansard Roof. Constructional Details. The preparing of a dormer of this descrip-tion is the work of a joiner rather than of acarpenter. A few leading particulars ofthe construction will now be given. Theangle posts are rebated and beaded to…
Carpentry · Joinery
