Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 22
Fig. 26.—Ordinary Joiners Bench fitted with Instantaneous Vice. HAND TOOLS AND APPLIANCES. receive the stop, which is of the patternshown by Fig. 32, so that it fits tightlyagainst the leg of the bench. Fig. 26 showsa joiners bench of another pattern, fittedwith a good form of instantaneous… … Fig. 27.—Bench with Side and Tail Vices. class of vice is shown in section at Fig. 31.A bench with side and tail vices is illus-trated at Fig. 27, and, although not muchused by joiners, is a very useful form forsmall work or as a portable bench. Thetop and tail vice cheeks contain holes forthe…
Carpentry · Joinery
